Product Description
Ø40mm Ceramic Cartridge
Low Torque Structure Type
With Distributor
Option : Temp. Adjuster, Noise Reducer, Water Hammer Solution Mechanism
  • CAP0050 Ceramic Cartridge Ø40mm OD
  • CAP0050 Ceramic Cartridge Ø40mm OD
  • CAP0050 Ceramic Cartridge Ø40mm OD
  • CAP0050 Ceramic Cartridge Ø40mm OD
  • CAP0050 Ceramic Cartridge Ø40mm OD
Product Description
Ø40mm Ceramic Cartridge
Low Torque Structure Type
With Distributor
Option : Temp. Adjuster, Noise Reducer, Water Hammer Solution Mechanism
Product Specification
Technical characteristics of the ceramic discs
Material AL2O3 92%~96%
Surface roughness Ra 0.1 ~ Ra 0.3 μm
Hardness ＞1000 HV
Flatness ＜0.6 μm
Technical characteristics of the cartridge
Max. opening angle 24.5°
Max. rotary angle 90°
Recommended nut tightening torque 10~12 N.m
Water resistance pressure 350~500 psi
Max. temperature 90℃(194℉)
Endurance test 500,000 cycles (ASME A112.18.1)
70,000cycles (EN817)
Flow rate
Water
pressure		 Hot water
(L/min)		 Cold water
(L/min)		 Mixing
(L/min)
1 bar 16.20 16.60 20.80
2 bar 23.00 23.00 26.80
3 bar 27.00 27.60 33.40
